Needle bearings-IMCB (Shandong) Bearing Manufacturing Co., Ltd

Needle bearings

Product Type：	Needle bearings
Contact person:	IMCB Bearings
Contact number:	0086-135 8118 0002
Contact email:	cbbearing@hotmail.com
Contact address:	Yandian industiral park, linqing city, shandong province ,china

Consultation hotline：
0086-135 8118 0002

Product Introduction

End face open type needle roller bearing with stamped outer ring

Stamped outer ring needle roller bearings are usually used in applications where the bearing housing hole cannot be used as a raceway for needle roller and cage components, but requires a particularly compact and economical bearing configuration. Due to the large number of rollers, the bearing capacity and stiffness are very large.

Product features:

High radial bearing capacity

High rigidity

Small cross section

Bearing model	Boundary Dimensions（mm）			Speed Rating(ipm)		Load Rating（kn）		Bearing type
Bearing model	d	D	B	Grease lubrication	Oil lubrication	Dynamic Cr	Static Cor	Bearing type
NKX 70 Z		85		44.6	98	3400	2700	Needle bearing
NKX 70		85		44.6	98	3400	4500	Needle bearing
NKX 60 Z		72		41.8	96.5	3600	3000	Needle bearing
NKX 60		72		41.8	96.5	3600	5000	Needle bearing
NKXR 50 Z		62		38	78	2200	4300	Needle bearing
NKX 50		62		38	78	4300	6300	Needle bearing
NKXR 50		62		38	78	2200	4300	Needle bearing
NKX 50 Z		62		38	78	4300	3600	Needle bearing
NKX 45 Z		58		27.5	57	4500	3800	Needle bearing
NKXR 45 Z		58		27.5	57	2200	4500	Needle bearing
NKXR 45		58		27.5	57	2200	4500	Needle bearing
NKX 45		58		27.5	57	4500	6300	Needle bearing
NKXR 40 Z		52		26.4	51	2400	5000	Needle bearing
NKXR 40		52		26.4	51	2400	5000	Needle bearing
NKX 40		52		26.4	51	5000	7000	Needle bearing
NKX 40 Z		52		26.4	51	5000	4000	Needle bearing
NKX 35		47		24.6	45	5600	7500	Needle bearing
NKX 35 Z		47		24.6	45	5600	4500	Needle bearing
NKXR 35 Z		47		24.6	45	2800	5600	Needle bearing
NKXR 35		47		24.6	45	2800	5600	Needle bearing
NX 35		47		24.6	45	5000	5600	Needle bearing
NX 35 Z		47		24.6	45	5000	3400	Needle bearing
NX 30 Z		42		22.9	38	5300	3600	Needle bearing
NKX 30		42		22.9	38	6000	8500	Needle bearing
NKXR 30 Z		42		22.9	38	3000	6000	Needle bearing
NKXR 30		42		22.9	38	3000	6000	Needle bearing
NX 30		42		22.9	38	5300	6000	Needle bearing
NKX 30 Z		42		22.9	38	6000	5000	Needle bearing
NKXR 25 Z		37		19	32.5	3200	6300	Needle bearing
NKXR 25		37		19	32.5	3200	6300	Needle bearing
