| Product Type： | Tapered roller bearings |
| Contact person: | IMCB Bearings |
| Contact number: | 0086-135 8118 0002 |
| Contact email: | cbbearing@hotmail.com |
| Contact address: | Yandian industiral park, linqing city, shandong province ,china |
Tapered roller bearing
Tapered roller bearings are designed to withstand combined radial and axial loads and have low friction during operation. The inner ring assembly with roller and cage can be installed separately from the outer ring. This separable and interchangeable bearing is easy to install, disassemble and maintain. Install a single-row tapered roller bearing and another bearing together to obtain preload and realize the application of rigid bearing.
Product features:
High axial and radial bearing capacity
Can bear one-way axial load
Low friction
Long service life
Detachable and interchangeable parts
| Bearing model | Boundary Dimensions（mm） | Speed Rating(ipm) | Load Rating（kn） | Bearing type | ||||
|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease lubrication | Oil lubrication | Dynamic Cr | Static Cor | ||
| T7FC 095/CL7CVQ051 | 95 | 180 | 275 | 400 | 2400 | 3400 | Tapered roller bearing | |
| T7FC 080T98/QCL7CDTC10 | 80 | 160 | 391 | 630 | 2200 | 4000 | Tapered roller bearing | |
| T7FC 080/QCL7C | 80 | 160 | 229 | 315 | 2800 | 4000 | Tapered roller bearing | |
| T7FC 075/QCL7C | 75 | 150 | 201 | 280 | 3000 | 4300 | Tapered roller bearing | |
| T7FC 070T83/QCL7CDTC10 | 70 | 140 | 303 | 480 | 2400 | 4500 | Tapered roller bearing | |
| T7FC 070/QCL7C | 70 | 140 | 176 | 240 | 3200 | 4500 | Tapered roller bearing | |
| T7FC 065/QCL7C | 65 | 130 | 157 | 216 | 3400 | 5000 | Tapered roller bearing | |
| T7FC 060T80/QCL7CDTC10 | 60 | 125 | 264 | 405 | 3600 | 5300 | Tapered roller bearing | |
| T7FC 060/QCL7C | 60 | 125 | 154 | 204 | 3600 | 5300 | Tapered roller bearing | |
| T7FC 055T73/QCL7CDTC10 | 55 | 115 | 216 | 325 | 4000 | 5600 | Tapered roller bearing | |
| T7FC 055/QCL7C | 55 | 115 | 125 | 163 | 4000 | 5600 | Tapered roller bearing | |
| T7FC 050/QCL7C | 50 | 105 | 108 | 137 | 4300 | 6300 | Tapered roller bearing | |
| T7FC 045/HN3QCL7C | 45 | 95 | 89.7 | 112 | 4800 | 7000 | Tapered roller bearing | |
| T4EE 160/VB406 | 160 | 245 | 528 | 980 | 1800 | 2600 | Tapered roller bearing | |
| T4EB 240/VE174 | 240 | 320 | 429 | 815 | 1300 | 1900 | Tapered roller bearing | |
| T4DB 200 | 200 | 270 | 330 | 600 | 1600 | 2400 | Tapered roller bearing | |
| T4DB 180 | 180 | 240 | 251 | 450 | 1800 | 2600 | Tapered roller bearing | |
| T4DB 170 | 170 | 230 | 251 | 440 | 1900 | 2800 | Tapered roller bearing | |
| T4DB 160 | 160 | 220 | 242 | 415 | 2000 | 2800 | Tapered roller bearing | |
| T4DB 150 | 150 | 210 | 233 | 390 | 2000 | 3000 | Tapered roller bearing | |
| T4CB 140 | 140 | 195 | 194 | 325 | 2200 | 3200 | Tapered roller bearing | |
| T4CB 120 | 120 | 170 | 157 | 250 | 2600 | 3800 | Tapered roller bearing | |
| T4CB 100/Q | 100 | 145 | 125 | 190 | 3200 | 4500 | Tapered roller bearing | |
| T3FE 075/QVB481 | 75 | 145 | 297 | 450 | 3400 | 4800 | Tapered roller bearing | |
| T2EE 240/VB406 | 240 | 320 | 616 | 1320 | 1300 | 1900 | Tapered roller bearing | |
| T2EE 100 | 100 | 165 | 314 | 480 | 2800 | 4300 | Tapered roller bearing | |
| T2EE 060/Q | 60 | 115 | 194 | 260 | 4300 | 6300 | Tapered roller bearing | |
| T2EE 040/QVB134 | 40 | 85 | 121 | 150 | 6000 | 9000 | Tapered roller bearing | |
| T2ED 070/QCLNVB061 | 70 | 130 | 233 | 325 | 3800 | 5600 | Tapered roller bearing | |
| T2ED 055/QCLN | 55 | 110 | 179 | 232 | 4500 | 6700 | Tapered roller bearing | |
