• Bearing model
• Model
  FAG WHEEL HUB BEARING 32314BA
• internal diameter-(mm)
• d
  70
• Outer diameter -(mm)
• D
  150
• Bearing thickness-(mm)
• B
  54
• Dynamic load-(kN)
• cr
  297
• Static load-(kN)
• cor
  380
• Fatigue load limit-(kN)
• Fatigue load limit
  45
• Reference speed-(r/min)
• Reference speed
  3200
• Limit speed-(r/min)
• Limit speed
  4500

FAG WHEEL HUB BEARING 32314BA  Tapered roller bearings are usually of the separated type, that is, the conical inner race assembly composed of the inner race with roller and cage assembly can be installed separately from the conical outer race (outer race). Tapered roller bearings are widely used in automobile, rolling mill, mining, metallurgy, plastic machinery and other industries。
