• Bearing model
• Model
  29422E - SKF Spherical Roller Thrust Bearing
• internal diameter-(mm)
• d
  110
• Outer diameter -(mm)
• D
  230
• Bearing thickness-(mm)
• B
  73
• Dynamic load-(kN)
• cr
  1180
• Static load-(kN)
• cor
  3000
• Fatigue load limit-(kN)
• Fatigue load limit
  325
• Reference speed-(r/min)
• Reference speed
  1600
• Limit speed-(r/min)
• Limit speed
  2800

At Quality Bearings Online, we stock the SKF Spherical Roller Thrust Bearing 29422E, a top-tier component renowned for its superior operation, durability, and reliability in demanding industrial applications. This bearing is designed to and allow for misalignment of the shaft while accommodating heavy axial loads in one direction and heavy radial loads at relatively high speeds, making it an ideal choice for heavy-duty machinery and equipment. The dimensions of this 29422E bearing are 110x230x73mm.

Key Features

High Load Capacity

The SKF 29422 E Spherical Roller Thrust Bearing has been specifically engineered by SKF to house a large number of rollers in order to optimise load distribution and support heavy radial loads and axial loads in one direction. This design provides consistently robust performance in challenging environments.

Self-Aligning Design

The 29422E bearing from SKF automatically compensates for misalignment of the shaft in relation to the housing caused by things like shaft deflection. This key feature reduces the risk of premature failure and extends its service life.

Enhanced Durability

Manufactured with high-quality materials and advanced heat treatment processes, the SKF 29422 E bearing is designed to ensure long-lasting durability and offer resistance to wear and tear.

Optimised Internal Geometry

The internal design of the SKF 29422E bearing minimises friction and heat generation during operation. This enhances operational efficiency and reduces maintenance requirements.
