• Bearing model
• Model
  FAG 7324XL-TVP-UA
• internal diameter-(mm)
• d
  60
• Outer diameter -(mm)
• D
  130
• Bearing thickness-(mm)
• B
  31
• Dynamic load-(kN)
• cr
  104
• Static load-(kN)
• cor
  76.5
• Fatigue load limit-(kN)
• Fatigue load limit
  3.2
• Reference speed-(r/min)
• Reference speed
  6700
• Limit speed-(r/min)
• Limit speed
  6700

BRAND: FAG ID: 7312 BG MADE IN: GERMAN  DESCRIPTION Category:Angular contact ball b. Ball rows:Single row bearing Material:Standard bearing steel Outer ring:Without flange/groove Seal:None, open bearing Clearance:Normal radial clearance Cage:Sheet steel cage Temperature range:-20 to +120 °C Tolerance class:Tolerance class P0/PN2 / ABEC 1 Arrangement:Standard version Contact angle:40 degree Weight:1,730 kg ProductID:10295400 Country of origin:Japan Customs tariff number:8482 1090 EAN:4549250200977 Dimensions Inner dimension: 60,000 mm Outer dimension: 130,000 mm Width: 31,000 mm PACKAGE INCLUDES: ONE (1) FAG  Bearing 7312 BG
