• Bearing model
• Model
  ZWZ 51238M thrust ball bearing
• internal diameter-(mm)
• d
  190
• Outer diameter -(mm)
• D
  270
• Bearing thickness-(mm)
• B
  64
• Dynamic load-(kN)
• cr
  382
• Static load-(kN)
• cor
  1240
• Fatigue load limit-(kN)
• Fatigue load limit
  8.4
• Reference speed-(r/min)
• Reference speed
  750
• Limit speed-(r/min)
• Limit speed
  1000

ZWZ 51238M thrust ball bearing Single direction thrust ball bearings can accommodate axial loads in one direction. They must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections. Many of the components are interchangeable. The shaft washers have a ground bore that enables an interference fit.
