• Bearing model
• Model
  ZWZ NU213E
• internal diameter-(mm)
• d
  65
• Outer diameter -(mm)
• D
  120
• Bearing thickness-(mm)
• B
  23
• Dynamic load-(kN)
• cr
  12.8
• Static load-(kN)
• cor
  12
• Fatigue load limit-(kN)
• Fatigue load limit
  94.5
• Reference speed-(r/min)
• Reference speed
  5900
• Limit speed-(r/min)
• Limit speed
  7000

This ZWZ cylindrical roller bearing with a polyamide cage and removable inner ring is suitable for applications that support high radial loads. This roller bearing has a CN (normal) radial clearance for applications and operating conditions with normal shaft and housing tolerances where thermal expansion is not a factor. This is a single row roller bearing that supports high radial loads with low friction. A removable inner ring in the open bearing allows application of lubrication. This roller bearing is measured in metric units for industry cross-matching and parts consistency.

Cylindrical roller bearings are used in applications where high radial loads are present such as in conveyer belts, traction motors, railway car axle boxes, and oilfield mud pumps, among others.

Roller or rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. They are usually composed of two rings, rolling bodies (such as bearings or cylinders), and a cage to house the parts. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. Rolling bearings can be open, shielded, or sealed. Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

ZWZ manufactures a variety of bearings that meet International Organization for Standardization (ISO) and Deutsches Institut für Normung (DIN) standards for quality assurance. Founded in 1883,ZWZ is based in Schweinfurt.
