• Bearing model
• Model
  NACHI 6204 ZZ ENR Deep Groove Ball Bearings
• internal diameter-(mm)
• d
  20
• Outer diameter -(mm)
• D
  47
• Bearing thickness-(mm)
• B
  14
• Dynamic load-(kN)
• cr
  13.5
• Static load-(kN)
• cor
  6.55
• Fatigue load limit-(kN)
• Fatigue load limit
  0.28
• Reference speed-(r/min)
• Reference speed
  32000
• Limit speed-(r/min)
• Limit speed
  20000

6204 Nachi Bearing 20mm x 47mm x 14mm Made in Japan 6204 Nachi Bearing, Made in Japan, the 6204 inner diameter is 20mm, the 6204 outer diameter is 47mm and the 6204 width is 14mm. * Item: 6204 Nachi Ball Bearing * Type: Nachi Deep groove Ball Bearing * Radial Clearance: C3 * Dimensions: 20mm x 47mm x 14mm/Metric * ID (inner diameter)/Bore: 20mm * OD (outer diameter): 47mm * Width/Height/thickness: 14mm * Size: 20 x 47 x 14 mm * Quantity: One Bearing * Dynamic load rating Cr: 12,800 N * Static load rating Cor: 6,600 N * Limiting Speed: * Grease Lubrication: 16,000 RPM * Oil Lubrication: 18,000 RPM * Made in Japan Nachi Deep Groove Ball Bearings Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements. The bearing ring grooves are circular arcs made slightly larger than the radius of the ball. The balls make point contact with the raceways (elliptical contact when loaded). The inner ring shoulders are of equal height (as the outer ring shoulders). Deep Groove ball bearings can sustain radial, axial, or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. Deep Groove ball bearings having an outside diameter less than 9 mm are known as Miniature ball bearings. Deep Groove ball bearings having an outside diameter => 9 mm and a bore diameter <10 mm are known as Extra-small ball bearings. Standard ball retainers (cages) are made from pressed steel. Machined cages are used in bearing operating at very high speed or for large diameter bearings. Deep groove ball bearings with seals or shields are standardized. They contain proper amount of grease in advance.
