• Bearing model
• Model
  JAPAN KOYO brand 6306RS
• internal diameter-(mm)
• d
  30
• Outer diameter -(mm)
• D
  72
• Bearing thickness-(mm)
• B
  19
• Dynamic load-(kN)
• cr
  29.6
• Static load-(kN)
• cor
  16
• Fatigue load limit-(kN)
• Fatigue load limit
  0.67
• Reference speed-(r/min)
• Reference speed
  11000
• Limit speed-(r/min)
• Limit speed
  20000

KOYO bearing deep groove ball bearing 6306rs Deep groove ball bearing can resist corrosion caused by moisture and other media. Provide closed (with seal or dust cover) or open design. Generally, there are grooves on the side of the open bearing ring, and seals or dust covers can also be installed.

The bearing capacity of this bearing is lower than that of high chromium steel bearing of the same size.

The stainless steel single-row deep groove ball bearing with outer ring and sealing or dust cover on both sides has higher chemical resistance and corrosion resistance. Because the deep groove ball bearing is widely used, has strong versatility and low friction, it can reduce noise and vibration after optimization, thus improving the rotating speed. It can bear radial load and two-way axial load, and is easy to install, requiring much less maintenance than other bearing types. The outer ring with retaining edge can position the bearing axially in the bearing seat. The embedded seal can greatly prolong the service life of the bearing, because it can prevent grease leakage and contamination from entering.

Characteristic:

Improved chemical and corrosion resistance

The outer ring with the retaining edge helps to position the bearing axially in the bearing housing

Embedded seal can prolong the service life of bearing

Typical advantages of single-row deep groove ball bearing
