• Bearing model
• Model
  FAG 1316 KM-C3
• internal diameter-(mm)
• d
  80
• Outer diameter -(mm)
• D
  170
• Bearing thickness-(mm)
• B
  39
• Dynamic load-(kN)
• cr
  33000
• Static load-(kN)
• cor
  89000
• Fatigue load limit-(kN)
• Fatigue load limit
  1810
• Reference speed-(r/min)
• Reference speed
  6000
• Limit speed-(r/min)
• Limit speed
  6300

The 1316-K-M-C3 FAG belongs to the group of double-row self-aligning deep-groove ball bearings. This bearing type without a seal is a double-row bearing. Both rows are housed in a spherical raceway in the outer ring. This construction allows the bearing to be self-aligning. This means that any misalignment of the shaft relative to the bearing housing does not adversely affect performance.

These features make the 1316-K-M-C3 FAG highly suitable for applications where substantial misalignment or shaft deflections may occur. Also, self-aligning bearings have the lowest friction of all rolling-element bearings. Even at higher speeds, there is only limited frictional heat. These bearings are capable of handling high radial loads. To a lesser extent, they can be axially loaded in both directions.
