• Bearing model
• Model
  HRB Ball Bearing 6208 ZZ
• internal diameter-(mm)
• d
  40
• Outer diameter -(mm)
• D
  80
• Bearing thickness-(mm)
• B
  18
• Dynamic load-(kN)
• cr
  18.1
• Static load-(kN)
• cor
  31.1
• Fatigue load limit-(kN)
• Fatigue load limit
  0.82
• Reference speed-(r/min)
• Reference speed
  9300
• Limit speed-(r/min)
• Limit speed
  11000

HRB Ball Bearing 6208 ZZDeep groove ball bearing, radial contact, pressed steel cage, shields on both sides

The single row deep-groove ball bearing is the most popular bearing. It is available in a wide range of sizes with several possible options: sealing with shields or seals, presence of a retaining ring, varied clearances, several cage types, etc.
