• Bearing model
• Model
  6205-C-2HRS-C3 FAG
• internal diameter-(mm)
• d
  25
• Outer diameter -(mm)
• D
  52
• Bearing thickness-(mm)
• B
  15
• Dynamic load-(kN)
• cr
  7.8
• Static load-(kN)
• cor
  15.9
• Fatigue load limit-(kN)
• Fatigue load limit
  0.485
• Reference speed-(r/min)
• Reference speed
  11000
• Limit speed-(r/min)
• Limit speed
  12700

Suffix description

C

Deep Groove Ball Bearings Of Generation C, Modified Internal Construction

2HRS

Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
