• Bearing model
• Model
  6204-C-2Z FAG
• internal diameter-(mm)
• d
  20
• Outer diameter -(mm)
• D
  47
• Bearing thickness-(mm)
• B
  14
• Dynamic load-(kN)
• cr
  6600
• Static load-(kN)
• cor
  13900
• Fatigue load limit-(kN)
• Fatigue load limit
  0.445
• Reference speed-(r/min)
• Reference speed
  18100
• Limit speed-(r/min)
• Limit speed
  20600

6204-C-2Z-C3 FAG (6204-ZZ-C3) Deep Grooved Ball Bearing Shielded 20x47x14 . Also known as: 6204-ZZ/C3, 6204-2Z/C3

FAG Generation C Single Row Deep Groove Ball Bearings. Thanks to design modifications such as improved bearing kinematics, new seals and cages as well as refined manufacturing processes, deep grove ball bearings of Generation C have numerous advantages including lower noise levels and lower friction.

Deep Groove Ball Bearings are the most common bearing type found in a wide variety of applications. Versatile and robust they are available in a wide range of sizes and options including seals, shields and special clearance for high speed applications. The main types are:

Open - Bearing without seals or shields, suitable for applications where lubricant will constantly flow through them i.e. gearboxes.

Metal Shields (2Z, ZZ) - Bearings fitted with steel shields and lubricated for life.

Rubber Seals (2RS, 2RSR, 2HRS) - Bearings fitted with steel reinforced rubber contact seals which provide a better seal but add friction so are unsuitable for high speed applications, lubricated for life.
