• Bearing model
• Model
  NACHI 6205 ZZ C3
• internal diameter-(mm)
• d
  25
• Outer diameter -(mm)
• D
  52
• Bearing thickness-(mm)
• B
  15
• Dynamic load-(kN)
• cr
  14.8
• Static load-(kN)
• cor
  7.8
• Fatigue load limit-(kN)
• Fatigue load limit
  0.335
• Reference speed-(r/min)
• Reference speed
  28000
• Limit speed-(r/min)
• Limit speed
  28000

Product characteristics Category:Deep groove ball bearings Ball rows:Single row bearing Material:Standard bearing steel Outer ring:Without flange/groove Seal:Cover on both sides Clearance:Slightly increased radial clearance Cage:Sheet steel cage Temperature range:-40 to +120 °C Tolerance class:Tolerance class P0/PN2 / ABEC 1 Current insulation:No current insulation Bore:Cylindrical bore Material of rolling elements:Standard bearing steel Weight:0,130 kg ProductID:10164150 Country of origin:Thailand Customs tariff number:8482 1090 EAN:4991893568851 Dimensions Inner dimension: 25,000 mm Outer dimension: 52,000 mm Width: 15,000 mm
