• Bearing model
• Model
  FAG 6214 Deep Groove Ball Bearing
• internal diameter-(mm)
• d
  70
• Outer diameter -(mm)
• D
  125
• Bearing thickness-(mm)
• B
  24
• Dynamic load-(kN)
• cr
  63.7
• Static load-(kN)
• cor
  45
• Fatigue load limit-(kN)
• Fatigue load limit
  1.9
• Reference speed-(r/min)
• Reference speed
  11000
• Limit speed-(r/min)
• Limit speed
  7000

Brand: FAG ID: 6214 MADE IN: GERMNAY DESCRIPTION: Category:Deep groove ball bearings Ball rows:Single row bearing Material:Standard bearing steel Outer ring:Without flange/groove Seal:None, open bearing Clearance:Normal radial clearance Cage:Sheet steel cage Temperature range:-20 to +120 °C Temperature range:-30 to +150 °C Tolerance class:Tolerance class P0/PN2 / ABEC 1 Current insulation:No current insulation Bore:Cylindrical bore Material of rolling elements:Standard bearing steel Weight:1,070 kg ProductID:10045694 Country of origin:Germany Customs tariff number:8482 1090 EAN:4012801077316 Manufacturer part number:016721152-0000 Dimensions Inner dimension: 70,000 mm Outer dimension: 125,000 mm Width: 24,000 mm PACKAGE INCLUDES: ONE (1) FAG 6210 OPEN
